Brushless Fan,DC Blower Fan,Brushless DC Blower Fan,50x50x25mm Sper fan
| Speed: 3000-5100rpm
| Total Airflow: 5.38-6.88 CFM
| Air Pressure: 4.96-16.56 mmH2O
| Total Noise: 25.5-37.1 dBA
| Bearings: Ball/ Sleeve/Fluid Bearing;.
** Cooling DC Blower Fan 5V/12V/24V 50x50x25mm Widely used in humidifier, aromatherapy,Car ventilation,Printer and other small appliances series; small heat radiating communication equipment; military equipment; intelligent industrial control equipment plate cooling heat, high precision medical equipment cooling; pc cpu server cooling dissipation and so on.
** Bearing: Pure copper bearing made in Japan. Guaranteed to continuously run 50,000 hours at temp 40℃ Humidity 5%~95%. Speed: 3000-5100 RPM customized.
Total Size : 50*50*25mm (L*D*H);
Cable Length : 25cm/9.8"/customized;
Mounting Spacing : 5.8cm/2.3";
Weight : 26.3g/pcs
**This fan is made of special and premium materials for Environmental protection and fire prevention PBT UL94V-0. It is high temperature resistant and extremely durable.
Size | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | ||
VDC | VDC | Amp | Watt | R.P.M | m3/min | CFM | mmH2O | INH2O | DB-A | |
50*50*25-LO5 | 5 | 3.6to6.8 | 0.20 | 1.00 | 3000 | 0.15 | 5.38 | 4.96 | 0.20 | 25.5 |
50*50*25-L12 | 12 | 7.0to13.5 | 0.11 | 1.32 | ||||||
50*50*25-M05 | 5 | 3.6to6.8 | 0.35 | 1.75 | 3500 | 0.16 | 5.75 | 6.64 | 0.26 | 28.0 |
50*50*25-M12 | 12 | 7.0to13.5 | 0.14 | 1.68 | ||||||
50*50*25-M24 | 24 | 18to26.5 | 0.08 | 1.92 | ||||||
50*50*25-HO5 | 5 | 3.6to6.8 | 0.35 | 1.75 | 4000 | 0.18 | 6.18 | 10.03 | 0.39 | 30.9 |
50*50*25-H12 | 12 | 7.0to13.5 | 0.20 | 2.40 | ||||||
50*50*25-H24 | 24 | 18to26.5 | 0.10 | 2.40 | ||||||
50*50*25-H12-HH | 12 | 7.0to13.5 | 0.25 | 3.00 | 5000 | 0.19 | 6.88 | 16.56 | 0.65 | 37.1 |
50*50*25-H24-HH | 24 | 18to26.5 | 0.12 | 2.88 |
